SD400.2 EVO 5

SKU: SD400.2 EVO 5
Power @ 2Ω: 2 x 200W Power @ 4Ω: 2 x 132W Bridge Power @ 4Ω: 1 x 400W Bridge Power @ 8Ω: 1 X 264W

150,00 €

400.2 EVO 5 – 4 OHMS

Power @ 1Ω: N/A
Power @ 2Ω: 2 x 200W
Power @ 4Ω: 2 x 132W

Bridge Power @ 4Ω: 1 x 400W
Bridge Power @ 8Ω: 1 X 264W

Frequency Response (-3dB):

10Hz ~ 20kHz

Low Pass Filter:

80Hz

High Pass Filter:

80Hz

Operating Voltage:

8V ~ 16V

SNR:

90dB

Input Sensitivity:

0.2V ~4V

Current Draw (Music):

18A

Current Draw With Resistive Load:

36A

Total Efficiency:

88%

Damping Factor:

200

Stereo Channel Minimum Impedance:


Bridge Minimum Impedance:


Recommended Fuse (Music):

20A

Recommended Battery (Minimum):

35Ah

Width:

4.4 in / 11.3 cm

Length:

4.7 in / 12.1 cm

Height:

2 in / 5.1 cm

Weight:

0.48kg
400.2 EVO 5 – 4 OHMS

Power @ 1Ω: N/A
Power @ 2Ω: 2 x 200W
Power @ 4Ω: 2 x 132W

Bridge Power @ 4Ω: 1 x 400W
Bridge Power @ 8Ω: 1 X 264W

Frequency Response (-3dB):

10Hz ~ 20kHz

Low Pass Filter:

80Hz

High Pass Filter:

80Hz

Operating Voltage:

8V ~ 16V

SNR:

90dB

Input Sensitivity:

0.2V ~4V

Current Draw (Music):

18A

Current Draw With Resistive Load:

36A

Total Efficiency:

88%

Damping Factor:

200

Stereo Channel Minimum Impedance:


Bridge Minimum Impedance:


Recommended Fuse (Music):

20A

Recommended Battery (Minimum):

35Ah

Width:

4.4 in / 11.3 cm

Length:

4.7 in / 12.1 cm

Height:

2 in / 5.1 cm

Weight:

0.48kg
